Taramps Bilforsterker DS 1200x4, 2 ohm 4x300W
DS1200X42 er en digital 4-kanals forsterker på hele 300 Watt RMS pr kanal i 2 Ohm.
Spesifikasjoner
- Operation class: D
- Number of Channels: 04
- Maximum power: @ 12.6 VDC - 2 OHMS: 1200W RMS (4 x 300W RMS)
@ 12.6 VDC - 4 OHMS: 768W RMS (4 x 192W RMS)
- Input Sensitivity: 250mV
- Signal to Noise Ratio: >88dB
- Frequency Response: 9Hz to 27KHz (-3dB)
- Crossover high pass (HPF): 90Hz (-12dB/8a) Fixed
- Crossover low pass (LPF): 90Hz (-12dB/8a) Fixed
- Input Impedance: 18K Ohms
- Output Impedance: 2 Ohms
- Protection system: Output overload
- Min. Supply Voltage: 9VDC
- Maximum Power Supply Voltage: 16VDC
- Consumption at rest: 1.8A
- Maximum music consumption: @12.6VDC 67.5A
- Maximum consumption in sinusoidal signal: 135A
- Dimensions (WxHxD): 182 x 52 x 281 mm
- Weight: 2,1 kg
